NP 350

NP 350: Compact, flexible and robust

The NP vertical form, fill and seal machines create net/film, PE, PP and laminated pillow and self-standing bags from a flat film on a reel. Pillow bags and self-standing bags can be produced on the machine. A continuous heated sealing system with exchangeable sealing profiles can handle a wide variety of packaging materials. The integrated handgrip punch system can create a handle in the top part of the bag. Bag length is determined by an encoder, guaranteeing a high level of accuracy.

NP 350 highlights

  • Stainless steel and open construction for easy cleaning
  • Robust build quality
  • Modular construction
  • Allen Bradley PLC and electrical components
  • Servo driven film transport for accurate bag length
  • Specially designed for net/film (Carry Bag), PE and PP materials
  • Block bottom /gusset mechanism
  • Handgrip sealing bars with air cooling
  • Photocell for bag length detection with pre-printed film
  • End of film detection
  • Film splice table
  • Ergonomic film support with film tensioning and brake
  • Low power and air consumption
  • Full colour touch screen
  • Machine in mobile frame

Download data sheet

Video: Modular design

Technical specifications

NP 350

Bag width (pillow)

75 - 350 mm

Max. bag length

Unlimited mm

Max. bag length per sealing step

480 mm

Max. production speed

40 bags/min

Film thickness

25 - 120 µ

Core diameter

76 mm (3")

Max. film width

750 mm

Max. outer diameter film roll

600 mm

Voltage

230 V, 50/60Hz

Power during production

1,200 Watt

Air consumption

6 bar, 200 l/min

All dimensions and specifications are indications based on standard set up. Final details depend on customer specifications.
